Ricoh D014 - Punch Unit B831; Accessories

Punch Unit B831
SM 1-111 D014/D015/D078/D079
Installation
1.14 PUNCH UNIT B831
The PU5000 Punch Unit (B831) is an accessory for the 3000-Sheet Finisher (B830).
1.14.1 ACCESSORIES
Check the accessories and their quantities against this list.
Description Q'ty
1. Punch Unit ................................................................................ 1
2. Punch Waste Collection Hopper ............................................... 1
3. Spacer (1 mm) .......................................................................... 2
4. Spacer (2 mm) .......................................................................... 1
5. Knob.......................................................................................... 1
6. Step Screw................................................................................ 1
7. Screw (M4 x 6) Black ................................................................ 1
8. Screw (M3 x 10) ........................................................................ 2
9. Spring........................................................................................ 1
10. Sensor Arm and Sensor............................................................ 1
B831I101.WMF
1
2
3
4
5
6
7
8
9
10
⇒
Rev. 03/2008
