MFP Controller Options
D014/D015/D078/D079 1-146 SM
1.18 MFP CONTROLLER OPTIONS
1.18.1 OVERVIEW
The machine controller box has three board slots and two SD card slots. Make sure that
each board and SD card is put in the correct slot.
Board Slots
No. Name Description
Slot A Copy Connector (B328) only
Slot B IEEE1284 (B679)
File Format Converter (D377)
IEEE802.11a/g (D377)
Bluetooth (B826)
Slot C Gigabit Ethernet (D377). The EFI (Fiery) controller is
connected through Gigabit Ethernet.
Rev. 08/2008
⇒
⇒
