Ricoh D014 - Ptr Motor

Motors
SM 3-131 D014/D015/D078/D079
Replacement
Adjustment
3.9.5 PTR MOTOR
1. Remove the rear covers.
2. Open the controller box door.
3. Remove the plate that holds the DRB [A] and DTMB [B] (x2,  x all)
4. Remove the PTR motor [A]( x4,  x1).
