Differences Between the D014/D015 & B132/B200
SM D-39 D014/D015/D078/D079
1. Heating Roller 10. Pressure Roller Fusing Lamp
2. Heating Roller Fusing Lamps x2 11. Cleaning Roller
3. Heating Roller Fusing Lamp x1 12. Oil Supply Roller
4. Heating Roller Thermistor 13. Pressure Roller Strippers
5. Entrance Guide 14. Fusing Belt Strippers
6. Pressure Roller Lift Mechanism 15. Hot Roller
7. Pressure Roller Lift Sensor 16. Fusing Belt Thermistor
8. Pressure Roller Thermistor 17. Fusing Belt
9. Pressure Roller
New Pressure Roller Lift Mechanism
A new pressure roller lift mechanism raises and lowers the pressure roller. When fusing
starts, the pressure roller lift motor switches on and raises the pressure roller against the hot
roller above. At the end of the job, the motor reverses and lowers the pressure roller away
from the hot roller. The hot roller and pressure roller remain separated while they are idle.
This prevents the pressure roller and hot roller from warping, and prolongs their service
lives.
