Used Toner Collection
D014/D015/D078/D079 6-30 SM
6.7 USED TONER COLLECTION
6.7.1 USED TONER PATH
[A] Used Toner Collection Coils [B] Horizontal Used Toner Transport Coil
PCU (Y) [C] Vertical Used Toner Transport Coil
PCU (C) [D] Diagonal Used Toner Transport Coil
PCU (M) [E] Used Toner Bottle Transport Coil
PCU (K) [F] Used Toner Distribution Coil
ITB Unit [G] Excess Toner Ports
PTR Unit
