Ricoh D014 - Shift Tray Exit Sensor

REPLACEMENT AND ADJUSTMENT
B830 12 SM
1.4.4 SHIFT TRAY EXIT SENSOR
Remove the top cover (

1.1.4)
Remove:
[A] Sensor bracket (

x1)
[B] Shift tray exit sensor 1 (

x1,

x1)
[C] Shift tray exit sensor 2 (

x1,

x1)
[A]
[
B
]
[C]
