REPLACEMENT AND ADJUSTMENT
B830 20 SM
Shift Tray Lift Motor
• Rear cover (
1.1.4)
[A] Gear cover (
x2)
[B] Shift tray lift motor bracket (
x2)
[C] Shift tray lift motor (
x,2
x1, Timing belt x1)
[A]
[B]
[C]
