Z-Folding Unit ZF4000 (B660)
SM 1-139 D014/D015/D078/D079
Installation
1.17.2 INSTALLATION
Always switch the machine off and unplug the machine before doing any of the
following procedures.
Unpacking
1. Detach the head of the I/F connector [A].
2. Remove all external tape [B] and shipping materials.
3. Open the front door [A].
4. Raise the horizontal transport plate [B] and remove the cushion [C].
To Next Page
