Ricoh D014 - Drive Layout; Main Drive

OVERALL MACHINE INFORMATION
SM 65 B830
Finisher
B830
4.2 DRIVE LAYOUT
4.2.1 MAIN DRIVE
1. Upper Transport Motor
2. Upper Tray Exit Motor
3. Shift Tray Lift Motor
4. Shift Tray Exit Motor
5. Stapler Exit Motor
6. Pre-Stack Transport Motor
7. Lower Transport Motor
B830V503.WMF
1
2
3
4
5
6
7
