MFP Controller Options
SM 1-163 D014/D015/D078/D079
Installation
8. Attach Antenna 1 [A] to the left front corner of the machine. (The core on the Antenna 1
cable is black.)
9. Set the cable of Antenna 1 in the clamps and close them.
10. Remove the seals from the cable clamps and attach them to the rear of the machine as
shown above.
11. Attach Antenna 2 [B] to the right rear corner of the machine.
12. Set the cable of Antenna 2 in the clamps and close them.
SP Mode Settings for 802.11a/g Wireless LAN
The following SP commands can be set for 802.11a/g
1. Go into the SP mode
2. Touch "Copy SP" on the touch-panel to open the SP command selection screen.
3. Do SP5840-11.
SP No. Name Function
5840 011 WEP Key Select Used to select the WEP key (Default: 00).
