OVERALL MACHINE INFORMATION
SM 31 B835
Cover
Interposer
Tray
B835
3.3 ELECTRICAL COMPONENTS
3.3.1 FEED MOTORS, PCB
1. 1st Paper Feed Motor
2. 1st Transport motor
3. 1st Pick-Up Motor
4. 2nd Pick-Up Motor
5. 2nd Transport motor
6. 2nd Paper Feed Motor
7. Tray Unit Control Board
B835V903.WMF
1
2
3
4
5
6
7
