Ricoh D014 - Exit Guide Motor; Lower Transport Motor

REPLACEMENT AND ADJUSTMENT
SM 33 B830
Finisher
B830
Lower Transport Motor
• Rear cover (

1.1.4)
[A] Lower transport motor (

x4,

x1)
Exit Guide Motor
• Top cover (

1.1.4)
[A] Bracket (

x2,

x1)
[B] Exit guide motor (

x2,

x1, Timing belt x1)
[A]
[A]
[B]
