Ricoh D014 - Service Call Tables; Sc Codes Group 1: Scanning

Service Call Tables
D014/D015/D078/D079 4-4 SM
4.2 SERVICE CALL TABLES
4.2.1 SC CODES GROUP 1: SCANNING
Exposure lamp error
SC101 D
The white level peak did not
reach the prescribed threshold
when the white plate was
scanned.
 Dirty optics
 Dirty white plate
 Exposure lamp defective
 Exposure lamp does not turn on
 Lamp stabilizer defective
 High voltage line leak
 SIB defective
 SBU defective
Scanner home position error 1
SC120 D
The scanner home position
sensor did not detect the
home position (did not go
OFF) after the scanner moved
forward 20 mm..
 Scanner motor defective
 Scanner HP sensor defective
 Harness between scanner motor
and SIOB disconnected or broken.
 SIOB defective
Scanner home position error 2
SC121 D
The scanner home position
sensor did not go ON after the
scanner moved forward 6 mm
and the feeler entered the HP
sensor.
 Scanner motor harness loose,
broken, defective
 Scanner motor defective
 Scanner HP sensor disconnected,
defective
 SIOB defective
