3.3.3 PAPER PATH SENSORS 1
1. 1st Tray Cover Sensor
2. 1st Pick-Up Roller HP Sensor
3. 1st bottom plate position sensor
4. 1st Transport Sensor
5. 1st Paper Feed Sensor
6. Vertical Feed Cover Switch
7. 1st Vertical Transport Sensor
8. 2nd Transport Sensor
9. 2nd Paper Feed Sensor
10. 2nd bottom plate position sensor
11. 2nd Pick-Up Roller HP Sensor
12. 2nd Tray Cover Sensor
B835V905.WMF
10
1
2
4
5
7
8
9
3
6
11
12
