REPLACEMENT AND ADJUSTMENT
SM 39 B830
Finisher
B830
1.9.5 STAPLE MOTORS
*
Staple Junction Gate Motor
Staple Junction Gate Motor
• Rear cover (
1.1.4)
[A] Staple junction gate motor (
x2,
x1,
x1)
[A]
