Differences Between the D014/D015 & B132/B200
D014/D015/D078/D079 D-26 SM
Different Designs of YCM PCU and K PCU
1 Charge Corona Unit (Scorotron type)
2 Charge Corona Wire Cleaner
Only the K PCU uses a charge
corona unit.
3 Charge Roller Unit
4 Charge Roller Cleaning Roller
5 Charge Roller
The Y, M, C PCUs use charge
rollers.
6 Lubricant Blade
7 Lubricant Brush Roller
8 Lubricant Bar
9 Cleaning Blade
10 Cleaning Brush Roller Flicker
11 Toner Collection Coil
12 Collection Coil
13 Quenching LED
These items comprise the PCU
cleaning system. The same parts
and system are used in all of the
four PCU units.
