Ricoh D014 - 3 Overall Machine Information; Main Layout

OVERALL MACHINE INFORMATION
SM 29 B835
Cover
Interposer
Tray
B835
3. OVERALL MACHINE INFORMATION
3.1 MAIN LAYOUT
1. 1st Pick-up Motor
2. 1st Transport Motor
3. 1st Paper Feed Motor
4. 1st Lift Motor
5. Driver Board
6. 2nd Pick-up Motor
7. 2nd Transport Motor
8. 2nd Paper Feed Motor
9. 2nd Lift Motor
10. Control Board
11. Door Open Switch (Interlock)
12. Horizontal Transport Motor
13. Vertical Transport Motor
B835V901.WMF
10
11
12
13
1
2
3
4
8
7
6
5
9
