REPLACEMENT AND ADJUSTMENT
B835 20 SM
1.6.6 ENTRANCE SENSOR
[A] Sensor unit (
x2,
x1,
x1)
[B] Entrance sensor (Pawls x2)
B835R122.WMF
[A]
[B]
