4.2.2 STAPLING TRAY DRIVE
1. Stack Feed-Out Belt Motor
2. Jogger Motor
3. Top Fence Motor
4. Positioning Roller Drive Motor
5. Positioning Roller Motor
6. Stack Plate Motor (Rear)
7. Stapler Movement Motor
8. Stack Plate Motor (Center)
9. Stack Plate Motor (Front)
10. Stapler Rotation Motor
B830V504.WMF
1
2
3
4
5
6
7
8
9
10
