SM 7-41 D014/D015/D078/D079
Specifications
LD 1 (2/2) Laser Diode 1, 2nd of a pair, 1 of 8.
PCB21
LD 1 (1/2) Laser Diode 1, 1st of a pair, 1 of 8.
LD 2 (2/2) Laser Diode 2, 2nd of a pair, 1 of 8.
PCB22
LD 2 (1/2) Laser Diode 2, 1st of a pair, 1 of 8.
LD 3 (2/2) Laser Diode 3, 2nd of a pair, 1 of 8.
PCB23
LD 3 (1/2) Laser Diode 3, 1st of a pair, 1 of 8.
LD 4 (2/2) Laser Diode 4, 2nd of a pair, 1 of 8.
PCB24
LD 4 (1/2) Laser Diode 4, 1st of a pair, 1 of 8.
PCB25 LSDB: K Front
Front Laser Synchronization Detector Board for Laser
Diode 4.
PCB26 LSDB: M Front
Front Laser Synchronization Detector Board for Laser
Diode 3.
PCB27 LSDB: C Front
Front Laser Synchronization Detector Board for Laser
Diode 2.
PCB28 LSDB: Y Front
Front Laser Synchronization Detector Board for Laser
Diode 1.
PCB29 LSDB: Y Rear
Rear Laser Synchronization Detector Board for Laser
Diode 1.
PCB30 LSDB: C Rear
Rear Laser Synchronization Detector Board for Laser
Diode 2.
PCB31 LSDB: M Rear
Rear Laser Synchronization Detector Board for Laser
Diode 3.
PCB32 LSDB: K Rear
Rear Laser Synchronization Detector Board for Laser
Diode 4.
