Motors
D014/D015/D078/D079 3-126 SM
3.9 MOTORS
Development Motor
Drum Cleaning Motor
Drum Motor
Paper Transfer Motor
1. Remove the rear covers.
2. Open and lock the controller box.
CÓPIA NÃO CONTROLADA
CÓPIA NÃO CONTROLADA
