3.3 DRIVE LAYOUT
1. Feed Motor
2. Feed Rollers
3. Fold Roller Motor
4. Lower Exit Rollers
5. Grip Rollers
6. 3rd Fold Roller
7. 2nd Fold Roller
8. 1st Fold Roller
9. Vertical Feed Rollers – 1
10. Vertical Feed Rollers – 2
11. Vertical Feed Rollers – 3
12. Vertical Feed Rollers – 4
13. Upper Exit Rollers
B660D103.WMF
1
2
3
9
4
10
11
12
13
5678
