Ricoh D014 - Docking the Next Peripheral Device

Cover Interposer Tray CI5000 (B835)
SM 1-131 D014/D015/D078/D079
Installation
Docking the Next Peripheral Device
The next peripheral device to the left of the cover interposer tray must be installed before
you can mount the tray unit on top of the transport unit of the cover interposer tray.
 The tray unit of the cover interposer tray is supported by the top of the next peripheral
device in line to the left, as well as the transport unit of the cover interposer.
 The next peripheral device to the left of the cover interposer must be set up and
docked to the cover interposer before the transport unit of the cover interposer can be
mounted.
Connect the next peripheral unit now.
 Z-Folding Unit B660 (See "Z-Folding Unit B660" in this section)
 3000-Sheet Finisher B830 (See "3000-Sheet Finisher B830" in this section)
 Never attempt to mount the cover interposer tray unit until the next device in line
(Z-Folding Unit B660, or 3000-Sheet Finisher (B830) has been docked to the
transport unit (base) of the cover interposer tray.
 To prevent bending the frame of the tray unit and damaging its alignment, always
remove the tray unit from the cover interposer tray transport unit at the following
times:
 1) Before disconnecting either the cover interposer tray or the next peripheral
device to the left, or
 2) Before doing any maintenance on either the cover interposer tray or the next
peripheral device to the left.
