Service Call Tables
D014/D015/D078/D079 4-8 SM
4.2.2 SC CODES GROUP 2: EXPOSURE
Polygon motor error: ON timeout
SC202 D
The polygon mirror motor
does not reach the targeted
operating speed within the
prescribed time.
Harness to polygon motor drive
board disconnected, defective
Polygon motor defective
Polygon motor drive board defective
Polygon motor defective.
Polygon motor error: OFF timeout
SC203 D
The polygon mirror motor
does leave the READY status
within 3 seconds after the
polygon motor switches off.
Harness to polygon motor driver
board disconnected, defective
Polygon motor defective
Polygon motor driver board
defective
Polygon motor defective.
Polygon motor error: XSCRDY signal error
SC204 D
The polygon motor stopped
operating while the LD unit
was firing.
Harness to polygon motor driver
board disconnected, defective
Polygon motor defective
Polygon motor driver board
defective
