Memory address command error
SC687
B
The VBCU does not receive a
memory address command
from the controller 120
seconds after paper is in the
position for registration.
 Turn the machine power off/on
 Check the controller board
connections
 Controller defective
4.2.7 SC CODES GROUP 7: PERIPHERALS
ARDF original pickup operation error
SC701 D
Even though the pickup motor is rotating clock-wise, the pickup roller
home position sensor cannot detect the position of the pickup roller.
 Pickup roller HP sensor harness loose, disconnected, defective
 Pickup roller HP sensor defective
 Pickup motor harness loose, disconnected, defective
 Pickup motor defective
 ARDF control board defective
ARDF bottom plate lift motor
SC705 D
The bottom plate HP sensor did not detect the home position of the
bottom plate after the bottom plate lift motor switches on and lowers the
bottom plate.
The bottom plate position sensor does not detect the position of the plate
after the lift motor switches on and raises the bottom plate.
 ARDF feed motor disconnected, defective
 Bottom plate HP sensor disconnected, defective
 ARDF main board defective
