PM Tables
SM 2-7 D014/D015/D078/D079
Preventive
Maintenance
2.3 PM TABLES
2.3.1 MAIN MACHINE
Symbol Key for PM Tables
I Inspect. Clean, replace, or lubricate as needed.
C Cleaning required.
R Replacement required.
L Lubrication required:
Silicone Grease 501 (52039502)
Grease Barrierta – S552R (A2579300)
Grease – KS660 – SHIN-ETSU
Grease – KD660B (D0149800)
Heat Resisting Grease MT-78
Launa Oil 40
G104 Yellow Toner (D0159500)
Zinc Stearate (D0159501)
Main Machine PM Parts
OPTICS
150K 200K 300K 450K 600K Note
Reflector C Optical cloth
1st Mirror C Optical cloth
2nd Mirror C Optical cloth
3rd Mirror C Optical cloth
Scanner Rails C Alcohol then dry cloth
Exposure Glass C
Exposure glass
cleaner
Toner Shield Glass C Optical cloth
⇒
Rev. 08/2008
