Copy Tray (B756)
SM 1-35 D014/D015/D078/D079
Installation
1.4 COPY TRAY (B756)
1.4.1 ACCESSORIES
Check the accessories and their quantities against this list.
Description Q'ty
1. Copy Tray 1
2. Actuator Arm and Bracket (not used) 1
3. Tapping Screw (not used) 2
4. Large Cap 1
5. Small Cap 4
6. Tapping Screw (M4 x 8) 1
7. Harness Clamp 1
8. Paper Height Sensor 1
9. Actuator Arm Bracket 1
10. Sensor Bracket 1
11. Actuator Arm 1
