Ricoh D014 - Pcu; Charge Units; Preparation

PCU
SM 3-33 D014/D015/D078/D079
Replacement
Adjustment
3.4 PCU
3.4.1 CHARGE UNITS
The procedure for removing the drum charge components in the K PCU and YMC PCUs is
different.
 The YMC PCUs use a charge roller to charge the OPC drum.
 The K PCU uses a charge wire unit to charge the OPC drum.
Preparation
1. Remove the PCU stand from the bottom of the machine.
2. Remove the PCU from the machine.
3. Set the PCU on the PCU stand.
 The PCU stands for the D014/D015/D078/D079 and B132/B200 copiers are
different. Be sure to use the PCU stand for the D014/D015/D078/D079. If you
use the PCU stand for the B132/B200, this could damage the exposed drum
on the bottom of the PCU.
