 It is not necessary to input the paper size setting for trays 2 and 3. This is detected
automatically.
Make a Test Color Print
1. Make sure that A3 or DLT paper is in one of the trays.
 Use the same type of paper that the customer normally uses for color outputs.
2. Put a "Color Chart C-4" on the exposure glass.
3. Select full color mode and print one copy of the chart. You will use this in the ACC
procedure, if ACC is necessary.
4. Check the results of the copy with the customer.
 If the quality of the color is satisfactory, ACC adjustment is not necessary.
 If the quality of the color is not satisfactory, do the ACC adjustment described
below.
ACC (Automatic Color Calibration) Adjustment
Automatic color calibration is done at the factory with the procedure given below. Do this
procedure only if the color quality is not satisfactory for the customer.
1. Push [User Tools] ().
2. To print a color pattern, select Maintenance> Auto Color Calibration
3. Touch "Start".
Machine will start self-check before
printing test pattern
Press [Start Printing].
4. Touch "Start Printing".
Now self-checking.
Test pattern will be printed.
Please wait.
The machine does process control, then it prints a test pattern.
Place Test Pattern on the exposure glass correctly.
Then press [Start Scanning]
5. Remove the C-4 test chart from the exposure glass (this was put on the exposure
glass during the previous procedure 'Make a Test Color Print').
6. Place the color test pattern face-down (this is the test pattern that you made in step 4).
The arrow and notation ("Face down and align the arrow with the rear left corner of the
exposure glass.") must be at the rear left corner.
