Ricoh D014 - Sc800:Overall System

Service Call Tables
SM 4-71 D014/D015/D078/D079
Trouble-
shooting
4.2.8 SC800: OVERALL SYSTEM
Error in STR (Suspend To RAM) control ASIC *GW SC816
B
Error is detected in the signal
from the ASIC, which controls
the STR (Suspend To RAM)
function
 ASIC (Controller Board) defective.
Turn the Main Switch OFF/ON. If the
SC reoccurs, replace the Controller
Board.
Note: STR is a newly-added feature of the D014/D015/D078/D079 copier, which further
minimizes energy consumption while the machine is in Energy Saver mode.
Boot loader error *GW
SC817 C
The boot loader cannot read
one of the following:
self-diagnostic module,
kernel, or one of the files of
the root file system, or the
check of one of these items
on the system SD card failed.
 File or module on the system SD
card is corrupted
 File or module on the system SD
card is illegal
 Make sure that the system SD card
is the one designed for the machine
 Replace controller board.
Fatal kernel error *GW
Due to a control error, a RAM overflow
occurred during system processing.
One of the following messages was
displayed on the operation panel.
 System program defective
 Controller board defective
 Optional board defective
 Replace controller firmware
0x696e init died
0x766d vm_pageout: VM is full
4361 Cache Error
SC819 C
Other
Note: For more details about this SC code error, execute SP5990 to print an SMC report so
you can read the error code list. The error code is not displayed on the operation panel.
⇒
Rev. 05/2008
