Ricoh D014 - 2 Details; Overview; Main Layout

OVERVIEW
B704 8 SM
2. DETAILS
2.1 OVERVIEW
2.1.1 MAIN LAYOUT
1. Support tray
2. Slip sheet tray
3. Pick-up roller
4. Feed belt
5. Separation roller
6. Grip roller
B470D001.WMF
6
5
1
2 3 4
