Ricoh D014 - Exit Guide Hp Sensor

REPLACEMENT AND ADJUSTMENT
B830 10 SM
1.4.2 EXIT GUIDE HP SENSOR
1. Remove the top cover. (

1.1.1)
2. Remove the left upper panel and left upper cover ( x 2,  x 2).
3. Remove:
[A] Sensor bracket [A] (

x 1).
[B] Exit guide HP sensor (

x 1,
Pawls x3).
[A]
[B]
