1.5.2 HORIZONTAL TRANSPORT MOTOR
Remove:
• Transport unit rear cover (

1.1)
[A] Motor unit (

x2,

x1, Timing belt x1)
[B] Horizontal transport motor (

x2)
B835R126.WMF
[A]
[B]
