Cover Interposer Tray CI5000 (B835)
SM 1-125 D014/D015/D078/D079
Installation
1.16 COVER INTERPOSER TRAY CI5000 (B835)
1.16.1 ACCESSORIES
Check the quantity and condition of the accessories in the box against the following list.
Description Q'ty
1. Spacer 1
2. Black Mylar 1
3. Relay Guide Plate – Long (for B234/B235/B236) 1
4. "L" Hinge Pins (Tray Unit Front Cover) 2
5. Sponge Strip 1
6. Leveling Shoes 4
7. Rear Docking Bracket 1
8. Front Docking Bracket 1
9. Flat Knob Screw 1
10. Screw (M4 x 8) 4
11. Screw (M3 x 6) 2
12. Screw (M4 x 12) 2
13. Knob Screw 3
14. Base Cover (Tray Unit) 1
15. Rear Cover 1
16. Screws (M4 x 14) 4
17.
Relay Guide Plate – Short (for D014/D015/D078/D079) includes the
following:
B4682196 (Guide Plate Upper) 1 pc
B8352191 (Guide Plate Lower) 1 pc
04513006N (M3x6 screws) 2 pcs
⇒
