Fusing Unit
SM 6-85 D014/D015/D078/D079
Detailed
Descriptions
Fusing Unit Specifications
Fusing Method Fusing Belt System
Fusing Lamps Heating Roller (3 halogen fusing lamps)
Pressure Roller (1 halogen fusing lamp)
Roller Diameters
Heating Roller: 35 mm
Hot Roller: 52 mm
Pressure Roller: 50 mm
Roller Thickness
Heating Roller: 0.6 mm
Hot Roller: 10 mm
Pressure Roller: 1.5 mm
Heat Detection Thermostats x3
Heating Roller Center x1
Heating Roller End x1
Pressure Roller x1
Thermistors x5
Heating Roller x3
Pressure Roller x1
Hot Roller x1
Fusing Unit Drive
Fusing/Exit Motor (Paper Transport)
Pressure Roller Lift Motor (Raises/lowers pressure roller)
