Fusing Unit
D014/D015/D078/D079 6-84 SM
1. Heating Roller 10. Pressure Roller Fusing Lamp
2. Heating Roller Fusing Lamps x2 11. Cleaning Roller
3. Heating Roller Fusing Lamp x1 12. Oil Supply Roller
4. Heating Roller Thermistor 13. Pressure Roller Strippers
5. Entrance Guide 14. Fusing Belt Strippers
6. Pressure Roller Lift Mechanism 15. Hot Roller
7. Pressure Roller Lift Sensor 16. Fusing Belt Thermistor
8. Pressure Roller Thermistor 17. Fusing Belt
9. Pressure Roller
A fusing belt and three rollers comprise the fusing unit. The rollers are:
Heating roller (fusing lamps x3)
Pressure roller (fusing lamp x1)
Hot roller (no fusing lamps).
The hot roller is composed of a new, softer sponge material that applies more even
pressure during fusing. Because the hot roller is very soft, a mechanism is provided to
retract the pressure roller from the hot roller and fusing belt when the machine is not
operating.
