Group 4000
D014/D015/D078/D079 5-136 SM
4301 Operation Check APS Sensor
This SP confirms that the APS sensors are operating correctly. Place a sheet of
paper on the exposure glass, then execute this SP code. For example, and A3
sheets returns the display 1111 1111 to indicate that all sensors are activated and
operating normally.
Note: Only the first 5 bits are used:
Bit 0: APS Sensor 1
Bit 1: APS Sensor 2
Bit 2: APS Sensor 3
Bit 3, APS Sensor 4
Bit 4: APS Sensor 5
4303 Min Size for APS
Sets the minimum size that the will be detected by APS
[0 to 2/1]
[*0: Unknown Document Size]
[1 A5-Lengthwise (HLT Lengthwise]
[2 A5 Sideways HLT Sideways]
4305 8K/16K Detection
This SP enables the machine to recognize 8K/16K size paper automatically.
[*0: Normal]
[1: A4-Sideways LT-Lengthwise]
[2: A4-Lengthwise LT-Sideways]
[3: 8KAI, 16 KAI]
