Specifications
D014/D015/D078/D079 7-42 SM
PCB33 Controller Board
Incorporates the GW architecture, and connects to the
BICU and PCI I/F. All the options for the printer are
controlled by this board.
PCB34 SCNB
Scanner Connector Board. Harnesses from the SBU
run into and out the SCNB, reducing the number of
harnesses from 2 to 1.
PCB35
OPU (Operation
Panel)
Controls the Operation Panel.
QUENCHING LAMPS
QL1 Quenching Lamp : K
Eliminates electrical charge and neutralizes the
surface of the drum in the Black PCU.
QL2 Quenching Lamp: C
Eliminates electrical charge and neutralizes the
surface of the drum in the Cyan PCU.
QL3 Quenching Lamp: M
Eliminates electrical charge and neutralizes the
surface of the drum in the Magenta PCU.
QL4 Quenching Lamp: Y
Eliminates electrical charge and neutralizes the
surface of the drum in the Yellow PCU.
Rev. 04/2008
⇒
⇒
