Mechanical Layout
SM 15 D350
D350
RT4000
A3/12 x 18
LCT
1. Paper Height Sensors ~, }, , {
2. Paper Width Sensor 3
3. Paper Width Sensor 2
4. Paper Width Sensor 1
5. Lift Sensor
6. Paper Assist Fan (Rear)
7. Paper Assist Fan (Front)
8. Entrance Sensor (Main Machine)
