Specifications
SM 7-49 D014/D015/D078/D079
Specifications
S53 Bypass Paper Size Sensor
Reads the positions of the side fences (manually
adjusted) to detect the width of the paper in the
bypass tray. (Paper length is read with pulse
counts from the registration sensor.)
S54 Paper Exit Relay Sensor
Detects paper jams at the paper exit if the paper
does not arrive or leave the machine at the
prescribed time.
S55
Copy Tray Full Sensor
(Option)
Detects when the Copy Paper Tray B75 is full
and temporarily pauses printing so the operator
can remove the stack from the tray and continue.
S56 TD Sensor: M
Monitors the amount of toner in the
developer/toner mixture in the development unit
of the Magenta PCU.
S57 TD Sensor: K
Monitors the amount of toner in the
developer/toner mixture in the development unit
of the Black PCU.
S58
Temperature/Humidity
Sensor: PCU K
The temperature and humidity readings of this
sensor are referenced to a lookup table stored in
the ROM to 1) Correct the charge roller voltage ,
and 2) Set the length of time the agitators in the
development unit rotate to mix the toner and
developer.
S59 TD Sensor: Y
Monitors the amount of toner in the
developer/toner mixture in the development unit
of the Yellow PCU.
S60 TD Sensor: C
Monitors the amount of toner in the
developer/toner mixture in the development unit
of the Cyan PCU.
Rev. 04/2008
