Copy Tray (B756)
SM 1-37 D014/D015/D078/D079
Installation
1. Attach the actuator [F] to the arms of the actuator arm bracket.
2. Reattach the left upper cover [A] ( x2).
3. Attach the tray [B].
4. Attach the small caps to the holes , , , .
5. Install the large cap [C] in the finisher power connection point.
