OVERALL MACHINE INFORMATION
SM 73 B830
Finisher
B830
Solenoids
No. Name Description
SOL Staple Trimming Chute
Solenoid
Opens and closes the trap door that drops staple trimmings into
the stapling trimmings hopper.
Switches
No. Name Description
SW Front Door Safety Switch Detects when the front door is open. The finisher does not
operate until the front door has been closed.
SW Emergency Stop Switch Switches the current job off and on to allow time for the operator
to remove paper from the shift tray.
SW Shift Tray Upper Limit Switch Cuts the power to the shift tray lift motor when the shift tray
position is at its upper limit.
