Read This First
Safety, Conventions, Trademarks
Conventions
Symbol What it means
Core Tech Manual
Screw
Connector
E-ring
C-ring
=
Harness clamp
FFC Flexible Film Cable
The notations "SEF" and "LEF" describe the direction of paper feed. The arrows indicate
the direction of paper feed.
