Mechanical Layout
D350 18 SM
Sensors
S Relay Sensor
Detects the leading and trailing edge of each to detect
jams in the horizontal paper path just before the paper
exits the LCIT.
Solenoid
No. Name Description
SOL Pick-up Solenoid Engages/disengages rotation of the pick-up roller in the tray.
