Ricoh D014 - Page 1456

Service Program Tables
SM 55 D356
D356
Fax Option
Type C7500
4.2.2 SP2-XXX (RAM DATA)
2 Mode No. Function
RAM Read/Write
101
001
Changes RAM data for the fax board
directly. See section 4.5 Service RAM
Addresses.
Memory Dump
001 G3-1 Memory Dump
Prints out RAM data for the fax board.
See section 4.5 Service RAM Addresses.
002 G3-2 Memory Dump
Prints out RAM data for the optional SG3
board.
003 G3-3 Memory Dump
Prints out RAM data for the optional SG3
board.
102
004 G4 Memory Dump Prints out RAM data for the SiG4 board.
G3-1 NCU Parameters
103
001 – 023 CC, 01 – 22
NCU parameter settings for the standard
G3 board.
See section 4.3 NCU Parameters.
G3-2 NCU Parameters
104
001 – 023 CC, 01 – 22
NCU parameter settings for the optional G3
board.
See section 4.3 NCU Parameters.
G3-3 NCU Parameters
105
001 – 023 CC, 01 – 22
NCU parameter settings for the optional G3
board.
See section 4.3 NCU Parameters.
