Bit Switches
D356 98 SM
Printer Switch 01 (SP No. 1-103-002)
No Function Comments
0-2 Not used Do not change the settings.
Maximum print width used in the
setup protocol
Bit 4 Bit 3 Setting
0 0 Not used
0 1 A3
1 0 B4
3-4
1 1 A4
These bits are only effective when bit 7 of
printer switch 01 is "1".
5-6 Not used Do not change the settings.
7
Received message width
restriction in the protocol signal
to the sender
0: Disabled
1: Enabled
0: The machine informs the transmitting
machine of the print width depending on the
paper size available from the paper feed
stations.
Refer to the table on the next page for how the
machine chooses the paper width used in the
setup protocol (NSF/DIS).
1: The machine informs the transmitting
machine of the fixed paper width which is
specified by bits 3 and 4 above.
Relationship between available paper sizes and printer width used in the setup
protocol
