SM ix D014/D015/D078/D079
PREVENTIVE MAINTENANCE
2. PREVENTIVE MAINTENANCE ...............................................2-1
2.1 OVERVIEW...........................................................................................2-1
2.1.1 REQUIRED MATERIALS.............................................................2-1
2.2 PM COUNTER......................................................................................2-3
2.2.1 DISPLAYING THE PM COUNTER ..............................................2-3
2.2.2 PM PARTS SCREEN DETAILS...................................................2-4
All PM Parts list: Main Menu............................................................2-4
Number button submenu.................................................................2-5
Parts list for PM yield indicator ........................................................2-6
2.3 PM TABLES..........................................................................................2-7
2.3.1 MAIN MACHINE ..........................................................................2-7
Main Machine PM Parts ..................................................................2-7
ARDF PM Parts.............................................................................2-14
2.3.2 LCT B473...................................................................................2-15
2.3.3 LCT D350...................................................................................2-16
2.3.4 2000/3000-SHEET FINISHERS D373/D374..............................2-17
2.3.5 PUNCH B702.............................................................................2-18
2.3.6 COVER INTERPOSER TRAY B704 ..........................................2-18
2.3.7 Z-FOLDING UNIT B660.............................................................2-19
2.3.8 3000-SHEET FINISHER B830...................................................2-19
2.3.9 PUNCH B831.............................................................................2-20
2.3.10 COVER INTERPOSER TRAY B835 ....................................2-20
2.4 LUBRICATION POINTS......................................................................2-21
2.4.1 COPIER .....................................................................................2-21
OPC, ITB Replacement.................................................................2-21
Fusing Unit ....................................................................................2-22
