PM Tables
SM 2-9 D014/D015/D078/D079
Preventive
Maintenance
150K 200K 300K 400K 450K 600K Note
Drum Cleaning
Brush Gear
R R
Development Unit L
Lube the Dev
Sleeve Shaft with
Grease – KS660B
Developer K R
Developer Y, M, C R
Quenching LED C C C
*
1
: The K PCU uses a charge corona system. The YMC PCUs use a charge roller system.
*
2
The lubricant bar is the same for both K and YMC PCUs when replaced as an individual
part. However, the drum lubricant bar assembly which contains the springs is not the same.
The K assembly is clearly marked "K" to prevent installation of the wrong type in a PCU.
TRANSFER UNITS
150K 300K 450K 600K Note
ITB Unit
ITB (Image Transfer Belt) R
ITB Unit Rollers I C
Wipe with dry
cloth
ITB Encoder Sensor C
ID and MUSIC Sensors C
Wipe with damp
cloth (alcohol)
ITB Cleaning Blade R
ITB Lubricant Bar R
ITB Lubricant Blade R
ITB Lubricant Brush Roller R
These items are
always replaced
as a set.
⇒
Rev. 08/2008
