PM Tables
SM 2-11 D014/D015/D078/D079
Preventive
Maintenance
150K 300K 450K 600K Note
Gears
L*
1
*
1
: The lubrication points for the fusing unit are described in the "Lubrication Points"
section.
PAPER FEED: COPIER
150K 300K 450K 600K Note
Registration Rollers C Alcohol, dry cloth
Paper Dust Removal Unit C Dry cloth
Registration Sensor C Blower brush
Vertical Transport Roller
Sensors
C Blower brush
LCT Relay Sensor C Blower brush
Bypass Feed Sensor C Blower brush
Bypass Paper End Sensor C Blower brush
PAPER FEED: Trays
150K 300K 450K 600K Note
Feed Guide Plate C Dry cloth
Grip Rollers (Drive &
Idle)
C Alcohol, dry cloth
Pick-up Rollers (Tray
1 to Tray 3)
Paper Feed Rollers
(Tray 1 to Tray 3)
Service Life: 1000K
Replace if jams,
double-feeds occur with
increasing frequency.
To Next Page
