Ricoh D014 - Page 482

Service Call Tables
D014/D015/D078/D079 4-32 SM
SC480 Drum cleaning motor error: K
SC481 Drum cleaning motor error: M
SC482 Drum cleaning motor error: C
SC483 Drum cleaning motor error: Y
The drum cleaning motor failed to
switch on (motor lock), or failed to
reach the required speed within
the prescribed time.
 Motor block by physical
obstruction
 Motor harness loose, broken,
defective
Motor defective
Used toner bottle full
SC484 D
The toner full sensor has
detected that the used toner
bottle is full.
 Remove the used toner bottle
 Empty the used toner bottle and
reinstall it
Used toner bottle motor error
SC485 D
The lock signal of the used
toner bottle motor remains
HIGH for more than 600 ms.
 Used toner bottle harness loose,
broken, defective
 Used toner bottle motor defective
Used toner bottle set error
SC487 D
The set sensor of the used
toner bottle remains LOW for
more than 500 ms. (The
sensor goes HIGH when the
bottle is installed correctly.)
 Used toner bottle not installed
 Remove used toner bottle and
reinstall correctly
